Wheel loader UR980
Products Description
Product Introduction:
Specification:
| Main Specifications | |
| Model | UR980 |
| Rated Payload | 7000kg |
| Bucket Capacity | 4.2-7.0m³ |
| Wheel Base | 3450mm |
| Minimum Turning Radius Over Bucket | 7790mm |
| Operating Weight | 23000kg |
| Length | 8840mm |
| Width | 3260mm |
| Height | 3530mm |
| Operating Specifications | |
| Breakout Force | 215kN |
| Dump Clearance | 3250mm |
| Drawbar Pull Force | 208kN |
| Dump Reach | 1310mm |
| Transmission | |
| Transmission Type | EH Control |
| Transmission Gears | F4/R3 |
| Engine | |
| Engine Model | Weichai WP10G270 |
| Rated Power | 199kW |
| Rated Speed | 2200r/min |
| Implement Hydraulic System | |
| Hydraulic Cycle Time | 9.8 |
| Implement Control Type | Pilot Control |
| Brake System | |
| Service Brake | Dry & Caliper, Air to Oil Control |
| Parking Brake | Drum Type Shoe Brake |
| Steering System | |
| Steering Angle (L/R) | 35° |
| Tires | |
| Size | 26.5-25 |
| Type | Bias |
| Layer | 24 |
| Textured Type | L3/E3 |
Product Detail:
